V-Cube™ Vertical Self-contained Systems

Vertical Self-Contained Systems

V-Cube™ Vertical Self-contained Systems

Floor-by-Floor Air Handling in New Construction or Retrofit Applications — 9 to 150 tons, 4,000 to 40,000 cfm

Our V-Cube Vertical Self-Contained Systems are famous for their quiet operation, compact design, and flexible configurations, making them an ideal solution for buildings of every type and size. Featuring a range of capacities and airflow, configurations, coil and filter options, exceptionally quiet and efficient fan options — including FANWALL TECHNOLOGY® — and additional features to improve your system’s performance, increase energy efficiency, or reduce sound levels, each V-Cube is custom designed and built to meet your project requirements. The compact footprint reduces the unit’s space requirements, and our knockdown capability allows the unit to fit through standard 3-foot doorways and in service elevators without breaking refrigerant lines. Additionally, the unit features independent refrigerant circuits, an easy maintenance design, and the EPiC™ system controls, which offer open protocol versatility (BACnet®, Modbus®, Johnson N2®, LonTalk®).

Want more information?

Find A Rep

Want more information?

Find A Rep

Benefits & Features

Flexibility
  • 9 to 150 tons capacity and 4,000 to 40,000 cfm airflow to match your application requirement.
  • Configurations include direct expansion (DX) with air cooled, water cooled, or glycol cooling; steam, hot water, or electric heat; airside or waterside economizer; and chilled water air handler.
  • Side, top, or down discharge for use in underfloor applications.
  • Flexible coil selections up to 10 rows, allowing use in a variety of applications, including low air temperature.
  • Multiple filter options including optional MERV13, 4-inch final filters with 2-inch pre-filters to provide superior indoor air quality.
Quiet Operation and Compact Footprint
  • Compact footprint reduces interior space requirements and allows for easier unit replacement.
  • Knockdown capability allows unit to fit through standard 3-foot doorways and in service elevators without breaking refrigerant lines.
  • Exceptionally quiet operation allows units to be placed adjacent to occupied spaces and can reduce attenuation costs. Coplanar Silencers® are available for enhanced acoustic performance.
High-Quality Construction
  • Integrated Thermal Break Framing™ (ITF) cabinet construction for industrial-grade, high-sealing integrity.
  • Airtight and watertight floor membrane to improve leakage characteristics and minimize sound transmission.
  • 3-inch R12.9 insulation in the walls, roof, and doors, a welded base frame (6-inch structural tubing perimeter), and double-seal thermal break doors.
  • Easy maintenance design, including unit tooled access panels, cleanable-in-place shell and tube condenser, and a dual sloped, stainless steel drain pan.
Energy Efficiency
  • Multiple coil and compressor combinations. Shell and tube condensers to minimize condensing temperatures and water pressure drop.
  • Variable Frequency Drive (VFD) selections for VAV operation allow efficiency to be optimized for each specific application.
  • Waterside economizer option provides the ability to take maximum advantage of free cooling opportunities to reduce energy consumption.
Multiple Fan Options, Including FANWALL TECHNOLOGY
  • FANWALL TECHNOLOGY increases the efficiency, quiet performance, and reliability of your system.
  • FANWALL TECHNOLOGY consists of an integrated system of state-of-the-art fans, efficient motors, controls, and accessories matched to your air handling requirements.
  • Eliminates belt, sheave, and bearing maintenance.

Technical Specifications

Airflow (cfm)
Small Frame

15,500

Small-tall Frame

20,900

Medium Frame

22,200

Medium-wide Frame

34,700

Large Frame

34,700

Large-wide Frame

41,650

Dimensions (Inches — Height x Width x Length)
Small Frame

81 x 100 x 49

Small-tall Frame

93 x 121 x 49

Medium Frame

112 x 103 x 55

Medium-wide Frame

112 x 124 x 55

Large Frame

112 x 125 x 62

Large-wide Frame

112 x 145 x 62

*Specifications for units with FANWALL TECHNOLOGY. See our V-Cube Vertical Self-Contained Systems Catalog (pdf) for additional options and technical specifications.
